Truck Bed Drawers for Pickup Trucks & SUVs
Truck bed drawers turn an open pickup truck bed into a secure, organized workshop that rides with you. No more climbing over the bed rail to dig through straps, extension cords and loose sockets. You pull a handle, a drawer rolls out toward the tailgate, and your gear is right there: dry, sorted, and still where you left it.
This guide compares the options that actually matter in 2026. Rugged ready-built units from DECKED, EZ STAK, Tuffy and MobileStrong. Custom aluminum builds. And the plywood setup a handy owner can finish in the garage. Several makers also build shorter units for SUVs, so the same logic applies to a cargo area as to a truck bed.
Here's the short version. If your truck is your job site, a heavy-duty system with real security and sealed drawers earns its keep in saved minutes every single day. If you haul camping gear twice a month, a lighter unit or a weekend build may be plenty.
DIY Truck Bed Drawers vs. Ready-Built Drawer Systems
Two roads, both valid. A DIY build is the budget route and fits your bed to the inch, but it costs you a few weekends and some woodworking skill. A ready-built unit installs in an afternoon and comes with a warranty and tested hardware. We break down both paths below, then compare the leading systems side by side.
What Is a Truck Bed Drawer System?
Think of it as a low cabinet that lives on the bed floor. Most units hold two long drawers that slide out toward the tailgate, with a flat deck on top that still carries cargo. Because the whole thing usually stands somewhere around ten to twelve inches tall, you keep most of your bed's depth for bikes, coolers or lumber.
It's a different animal from a classic toolbox. A crossover box sits up on the rails behind the cab and holds a few hand tool bags. A drawer unit uses floor space you were wasting anyway and puts every item within arm's reach from the back of the truck.
Who buys them? Electricians and plumbers who are tired of hunting for one fitting. Overlanders who need a kitchen, recovery gear and water in fixed spots. Hunters. And plenty of everyday haulers who simply want their stuff secured and out of sight.
Truck Bed Storage Drawers vs. Truck Bed Organizers
A truck bed organizer is usually open: cargo bars, nets, a plastic bin or a divider kit that stops groceries from sliding around. Cheap and useful storage options, but nothing is secured or covered. A storage drawer is enclosed, sits under a lid or deck, and keeps rain, dust and passersby away from what's inside. If you leave tools in the truck overnight, that difference matters more than anything else on this page.
Bed Tool & Truck Tool Storage for Cargo Management
A standard truck bed tool box rides across the rails, so it eats into top space and can block a rack or tonneau. Drawers leave the rails free. They also make truck tool organization stick, because every impact driver, meter and socket set gets its own spot instead of one shared pile. On many 8-ft beds, a full-length unit raises the floor above the wheel wells, so a 4x8 sheet of plywood can lie flat on the deck. That's cargo management you can feel on the next job.
Types of Truck Bed Drawer Systems: Material & Build
Material decides weight, weather resistance, noise and how long the unit looks good. Build style decides how you reach your gear. Get both right and you won't think about the system again for years.
HDPE, Aluminum & Steel Drawer Systems
HDPE (high-density polyethylene). DECKED molds its drawers and deck from HDPE over a steel frame, and MobileStrong uses recycled HDPE and phenolic panels. HDPE won't rust, shrugs off dents and has no paint to chip. Downside: it's bulkier than metal.
Aluminum. Highway Products builds custom units from thick-gauge aluminum. You get a sleek, light, corrosion-resistant box that suits fleet trucks and service bodies. It can dent under a dropped jack, and it's usually the premium choice.
Steel. Tuffy's security drawers use steel for one reason: theft resistance. Steel is durable and hard to pry, but heavy, and it needs a good finish to keep rust away.
Plywood. The DIY favorite, and the core of some commercial units too. It's easy to cut, quiet, and warm to work with for any woodworker. It needs sealing, and it's heavier than HDPE at the same strength.
Retractable Slide-Out Truck Bed Drawers
Not every slide-out product is a drawer. A retractable cargo tray like BedSlide is a flat platform that rolls out past the tailgate so you can load heavy items without climbing in. Drawers, by contrast, are boxes with sides. Check the extension too: full-extension runners expose the whole drawer, while cheaper glides stop short and leave the back third hard to reach.
Full-Size vs. 2-Drawer Storage Systems
A full-size unit runs nearly the length of the bed. You get the most volume, but also the most weight. Compact options cover less floor: a 2 drawer half-bed package (Dirtbox Overland offers one), a single drawer series like EZ STAK's, or MobileStrong's HDP wheel well storage drawer that tucks beside the wheel arch. Short units make sense if you still need open bed length for an ATV or furniture.
Truck Bed Storage Boxes & Toolbox Alternatives
Not ready for a full drawer setup? A truck bed storage box, side-mount chest or crossover box still beats a loose pile. Just know the trade-off: lids open upward, so you're digging from above, not pulling gear toward you.
Pick your material first, then compare today's prices on the systems that use it.
Load Capacity, Bracket Strength & Heavy-Duty Build Quality
Load ratings are where marketing gets slippery, so read them closely. There are usually three numbers: what the deck holds, what each drawer holds, and what the runners hold when fully extended. They're rarely the same.
For reference, DECKED lists a deck payload around 2,000 lb and roughly 200 lb per drawer. EZ STAK advertises a 750 lb rating, and Dirtbox Overland quotes 440 lb for its system. Always check which part of the unit a figure refers to before you trust it with a generator.
Strength also lives in the mounting hardware. Good units clamp to the factory tie-down points or bed rails with steel brackets, so the box can't shift under hard braking. DIY builders often reinforce stress points with quarter-inch steel bracket plates, and that habit is worth copying.
Drawer Dividers & Cargo Organization
Drawer dividers keep a socket set from turning into a pile by the first corner. Look for adjustable systems you can move as your kit changes. On homemade builds, a fixed panel near the front can also shield the latch rod from loose tools, which keeps it from jamming.
T-Handle & Locking Mechanism Durability
Most locking drawers use T-handles linked to a cam or rod. Cheap ones bend when people use them to yank a loaded drawer open, and a separate pull handle takes that strain off the locking mechanism. Homemade versions often use a steel pin secured with cotter pins, which is crude but very hard to defeat. Whatever you buy, check that the hardware sits flush, that the finish has a tough coating, and that nothing will scratch your gear as the drawer slides past.
Need serious security for expensive tools? See current pricing on steel-built units.
Waterproof & Lockable Truck Bed Storage Drawers
Straight talk: almost no truck bed drawer is truly waterproof. Good units are weather-resistant, which means they shed rain and keep out most dust, but standing water and pressure washers can still find a way in. If you run an open bed, plan for that.
Weather Guard Seals & Dust Protection
Check three things. A continuous rubber seal along the lid or deck edge. Overlapping drawer faces that shed water outward. And drain paths, so any water that does get in can leave. Some home builders bore a small drain hole at the low corner of each drawer for exactly this reason. Toolbox makers like Weather Guard use the same logic. On gravel roads, dust is the bigger enemy, and a sealed lid matters more than heavy walls.
UHMW Glides & Carpet-Lined Drawer Fronts
UHMW plastic glides are slick, cheap and nearly indestructible, which is why home builders and some manufacturers use them in place of ball-bearing runners. They don't rust and don't mind grit. Inside, a carpet lining on the floor and drawer fronts stops tools from rattling and protects finished gear such as a bow case or camera bag. Want a tidier interior? Drop in a plastic bin for small parts and the carpet keeps it from sliding.
Truck Bed Drawer Compatibility by Make & Model
Fit is the number one reason people return a drawer unit. Bed length, wheel well spacing, bed-side storage and tailgate style all vary by make and model, and sometimes by model year. Use the table as a starting point, then confirm on the listing.
| Truck | Common bed lengths | Fit notes |
|---|---|---|
| Ford F-150 (Ford F-Series) | 5.5 ft, 6.5 ft, 8 ft | Widest aftermarket support; check Pro Access tailgate fit |
| Ford Maverick | 4.5 ft | Compact bed; needs Maverick-specific or short units |
| Ram 1500 / Dodge Ram | 5 ft 7 in, 6 ft 4 in | RamBox models need RamBox-specific fitment |
| Chevy Silverado 1500 / GMC Sierra | About 5.8 ft, 6.6 ft, 8.2 ft | Multi-function tailgates can change the rear gap |
| Toyota Tacoma / Tundra | 5 ft, 6 ft / 5.5 ft, 6.5 ft, 8.1 ft | Overland favorites; mid-size units differ |
| 2500 heavy-duty trucks | About 6.3–6.75 ft, 8 ft | Taller beds; confirm height and tie-down spacing |
Ford F-150 & Ford Maverick Drawer Fit
The F-150 is the best-supported truck in this category, which makes sense given Ford Motor Company sells more of them than anything else. Most brands list separate fitments by bed length, so a Ford F150 with a 5.5-ft bed needs a different unit than the 6.5-ft version. The Maverick is a different story. Its short, narrow bed rules out full-length systems, and owners often build their own or pick a single compact drawer.
Ram 1500, Dodge Ram & Chevy Silverado Bed Drawers
On a Ram 1500, the big question is RamBox. Those side compartments narrow the usable floor, so only RamBox-specific units fit. Older Dodge Ram trucks, built before the Ram pickup became its own brand in 2010, need fitments listed for their model years, so double-check rail height. Chevy Silverado and GMC Sierra share beds, so a unit listed for one generally fits the other in the same year range.
BedSlide & Wheel Well Clearance by Cab Size
Cab size changes bed length, and bed length changes everything. Crew cabs usually pair with shorter beds; regular and extended cabs often get the long one. Measure between the wheel wells too. Most full-width drawer units run their drawers in the gap between the wells and rest the deck on top. If you want both drawers and a BedSlide tray, buy a combo designed to stack, because the tray adds height and needs its own clearance front and back.
Truck Bed Size (5.5–8 ft) & Tailgate Clearance
Measure from the bulkhead to the inside of the closed tailgate, at floor level. Some systems leave a small gap at the rear; others sit close enough that a newer multi-function gate drags on the drawer face. Also check the full-size truck bed depth if you plan to add a topper or tonneau, since the deck height eats into that space.
Most listings let you filter by truck and bed length. Check today's price for your exact fitment.
DIY Truck Bed Drawers vs. Buying a Ready-Built Drawer System
Building your own is a classic do it yourself project, and plenty of owners still use drawers they built years ago. It's not free, though. You trade money for time, tools and the risk of a design flaw you only notice at highway speed.
Materials List & Build Cost (2x8 Lumber, Screws, Strap Hinges)
A typical materials list for a 6.5-ft bed, based on popular builds:
- 2x8 lumber for the frame (some builders use 2x10s or 2x12s for a taller unit)
- 3/4-in plywood for the deck, drawer bottoms and the top and bottom panels
- 1x6 boards for the sides of the drawer and the drawer fronts
- Exterior-grade screws and construction adhesive
- Strap hinges for a flip-up lid over a top compartment
- UHMW strips for glides, plus a stop block per drawer
- Indoor-outdoor carpet, steel brackets, a steel locking rod, cotter pins and T-handles
- Protective coating such as bed liner or a rubberized sealer
The total cost lands in the budget tier, well below most branded systems. But price in the blades, hardware and any tools you don't already own.
Installation Time, Tools & Skill Level
Expect a circular saw, table saw, sander and ideally a drill press. Square 2x8s aren't hard to frame, but drawers that run true for years take patience. A tip from long-time builders: dab lipstick on the end of the locking rod, close it against the frame, and you'll see exactly where to drill a hole. First-timers should plan on more than one weekend. A ready-built unit, by contrast, usually installs in a few hours with basic hand tools and often needs no new holes in the bed.
Expert tip: Build your drawers to fit their pockets after the frame is assembled and sitting in the truck. Beds aren't perfectly square, and measuring the real opening saves you from drawers that bind.
Not sure you want to spend those weekends? Compare a few ready-built systems below before you buy lumber.
Check priceCompare Top Truck Bed Drawer Systems Side by Side
Material, Load Capacity & Price Comparison Table
| System | Material | Load rating (per maker) | Price tier | Install | Warranty | Check price |
|---|---|---|---|---|---|---|
| DECKED | HDPE over steel frame | Deck ~2,000 lb; ~200 lb per drawer | Mid to premium | Bolt-in, no drilling | Check listing | Check price |
| EZ STAK | Metal (see listing) | 750 lb | Mid to premium | No-drill | Lifetime | Check price |
| Dirtbox Overland | Metal, dual slide-out decks | 440 lb | Premium | Bolt-in | Check listing | Check price |
| MobileStrong HDP | Recycled HDPE / phenolic | Check listing | Mid to premium | Bolt-in | Check listing | Check price |
| Highway Products | Thick-gauge aluminum | Custom | Premium | Custom fit | Lifetime | Check price |
| TruckVault | Custom lockable build | Custom | Premium | Custom fit | Check listing | Check price |
| Tuffy security drawer | Steel | Check listing | Mid-range | Bolt-in | Check listing | Check price |
| VEVOR | Varies by model | Check listing | Budget | Bolt-in | Check listing | Check price |
| DIY plywood build | Plywood + 2x8 frame | Depends on build | Budget | You build it | None | Check price |
A few patterns stand out. HDPE units like DECKED hit the best balance of weight and weather resistance for most owners. Steel wins on security. Aluminum and custom builds suit fleets that want a tailored layout and can wait for it. TruckVault, for instance, builds lockable units around your truck and gear rather than selling off the shelf.
Ratings and fitments change by model year. Check the current listing for your truck before you order.
Truck Bed Drawer Prices: Budget DIY vs. Premium Storage Systems (2026)
We don't print numbers here. Amazon prices shift weekly, and a stale figure helps nobody. What we can do is show you where each option sits and what moves the price.
- BudgetDIY builds · VEVOR
- Mid-rangeDECKED · Tuffy · bolt-in systems
- PremiumCustom aluminum · TruckVault-style vaults · overland
Total Cost Breakdown: 2023–2026 Models
Think in three tiers. Budget: DIY builds and basic import units like VEVOR. Mid-range: mainstream bolt-in systems from DECKED, Tuffy and similar brands. Premium: custom aluminum, TruckVault-style vaults and any fully configured overland storage system. For trucks from 2023 onward, add any model-specific adapter, divider kit or drawer liner to the total, and count shipping on large freight items. A heavy-duty 2500 truck may need a taller unit, which usually costs more.
What Affects Truck Bed Drawer Pricing
Material is the biggest driver: steel and thick aluminum cost more than HDPE or plywood. After that come warranty length, slide hardware, made-to-order fitment and brand reputation. A longer warranty often signals better hardware, so it's worth weighing against the sticker.
Prices change daily. See today's number instead of trusting an old screenshot.
Truck Bed Drawers FAQ
How do I choose truck bed drawers that fit my truck's make, model, and bed size?
Start with year, make, model, cab and bed length, then measure between the wheel arches and from bulkhead to gate. Buy only units that list your exact fitment, and watch for RamBox, multi-function gates and factory bed liners.
How do I build and install DIY truck bed drawers?
Frame the unit with 2x8 lumber sized to your bed, cut drawers to fit the real openings, line them with carpet, add UHMW glides, then fit the locking rod and handles. Secure the finished unit to the tie-down points so it can't slide.
How much weight can truck bed drawers hold?
It varies widely. Published ratings run from a few hundred pounds (Dirtbox Overland's 440 lb, EZ STAK's 750 lb) to around 2,000 lb on a DECKED deck. Per-drawer limits are lower, so heavy items belong on top.
Are truck bed drawers waterproof and dustproof?
Most are weather-resistant rather than fully sealed. Good gaskets and overlapping fronts keep out rain and most dust, but don't leave electronics inside an open bed through a storm without a cover.
Will there be a gap between the drawer system and my tailgate?
Often a small one, by design, so the gate can close without rubbing. The exact gap depends on the brand and your gate style; the fitment notes on each listing usually spell it out.
Can truck bed drawers be used with a tonneau cover or truck topper?
Yes, in most cases. The drawers sit below rail height, so a tonneau or truck topper fits over them. You lose some vertical space on the deck, so measure tall items like coolers before you commit.
Is a drawer system easy to install without drilling (no-drill)?
Many are. Units from DECKED and EZ STAK, for example, anchor to existing tie-down points with no-drill install hardware. That's handy on a leased truck. Plan on a second person, since full-size units are heavy to lift into the bed.
What is the DECKED drawer system made of?
DECKED uses molded HDPE drawers and deck over a steel frame, which keeps rust off the outer surfaces and stands up to dents.
How much do truck bed drawer systems cost?
DIY builds are the cheapest, mainstream bolt-in units sit in the middle, and custom aluminum or vault-style systems are premium. Check the live listing for today's price.
Which truck bed drawers are best for tools and gear?
For contractors, a lockable system with adjustable dividers and a strong deck, such as DECKED or EZ STAK. For security-first owners, a steel unit like Tuffy. For overland trips, a dual-slide setup like Dirtbox Overland.
Found your answer? Check current price and fitment for your truck.
Find the Right Truck Bed Drawer System for Your Truck Today
Four questions settle almost every decision. Which material suits your climate and security needs? How much weight will the drawers and deck really carry? Does the unit list your exact bed and tailgate? And which price tier makes sense for how often you use the truck?
Answer those, and the shortlist gets short fast. Most owners land on an HDPE or steel bolt-in unit; builders with time and tools make their own. Either way, the right setup means your gear is secure, dry and ready the moment you drop the gate.
